Cable gland 1/2″ 20 Brass | Armoured | NPT

Description

CABLE GLAND FOR ARMOURED CABLES, BRASS , NPT 1/2", SIZE 20, Marking according to 2014/34/EU (ATEX): II 2 GD Ex db IIC Gb, II 2 GD Ex eb IIC Gb, II 2 GD tb IIIC Db Ambient temperature: -55°C do +160°C IP rating according to EN 60529: IP66/IP68 Overall cable diameter: from 12,5mm to 20,9mm Cable bedding diameter: from 8,0mm to 13,9mm

• ATEX / IECEx: II 2 GD Ex db IIC Gb, II 2 GD Ex eb IIC Gb, II 2 GD tb IIIC Db
• Ambient temperature: -55°C do +160°C
• IP rating: IP66/IP68
• Overall cable diameter: 12.5–20.9 mm
• Cable diameter under sheet: 8.0–13.9 mm
